Installation and Mounting:

Suitable for wall mounting: Yes
Not suitable for  – pendulum suspension
– ceiling mounting
– flush mounting
Suitable for surface mounting: Yes
Not suitable for continuous-row configuration

Lighting Details:

Interchangeable LEDs used as light source
With light source: Yes
Number of lamps/modules: 1
Socket: Other

Housing Details:

Plastic used as housing material
White used as housing color
Opaline plastic used for lid material
Electrical Details:

Voltage type: AC DC
Nominal voltage: 230-230V
Rated current: 35-35mA
Device: Not required
With device: No
Dimming Details:

No dimming capabilities:

Dimming 0-10V
Dimming 1-10V
DALI dimming
DMX dimming
DSI variation
Dimming by potentiometer (integrated)
GPRS variation
Dimmable LineSwitch
Manufacturer proprietary system variation
Mains voltage modulation dimming
End of phase break
Phase start cut
Programmable dimming
RF Dimming
Variation Sine Wave Reduction
Touch and Dim variation
Zigbee variation
Dimming with push button
Variation depending on the order

No change: Yes

Light Distribution:

Streamer used as light distribution element
Light distribution: Symmetrical
Beam angle: diffuse beam
Light output: Direct

Energy Efficiency:

Integrated lamp: A++, A+, A (LEDs)
Exchangeable lamp supplied: A+
Max. exchangeable lamp: A+

Protection:

IP24 as protection class (IP)
IK04 as impact resistance
Class II as protection class
Temperature and Climate:

Nominal ambient temperature according to IEC 62722-2-1: 5-25°C
Operating/installation temperature: 5-35°C
Storage temperature: 5-35°C
Sensor and Control:

Not suitable for emergency lights
With motion sensor: Yes
With light sensor: Yes
Physical Attributes:

Width: 60mm
Height/depth: 77mm
Length: 470mm
Suitable for through-wiring as type of wiring
Number of poles: 2
Conductor section: 2.5mm²
Screw terminal used as type of connection
Maximum cable entry diameter: 16mm
Between axis of horizontal fixing: 202-202mm
Other cable hold
Terminal capacity: 1.5-2.5mm²
Other Details:

Not – compatible with Apple HomeKit
– works with Google Assistant
– works with Amazon Alexa
– possible IFTTT support
Estimated bulb life: 25000 h
Mandatory neutral: Yes
RAL number: 916
Halogen free: Yes
No – antimicrobial treatment
– equipped with power socket(s)
– rain protection visor
– an additional light signal
– remote control supplied
– automatic switch
Order method: Wired
Not addressable
Not connected object
EAN/gencode: 329229050
